We have you covered with built-in temperature, humidity, air pressure, sound, 3-axis vibration and expandable analog inputs for all your measurement needs. With industry leading energy efficiency our tiny sensors are able to last for over three years. Compact and waterproof, mount them anywhere you wish. External analog sensor options are available upon request.
TEMPERATURE: -40C to +85C +/- 1.5C
HUMIDITY: 0% to 95% with no condensation +/- 3%
AIR PRESSURE: 300 hPa to 1100 hPa +/- 1 hPa
3-AXIS ACCELERATION: +/- 2g, 8-bit, 400Hz (continuous), 1.62 kHz (intermittent)
SOUND: 50dB to 120dB, 20 kHz
ANALOG IN: 2 x pin inputs for measuring up to 3.3V
PROTOCOL: BLE 5.0
RANGE: Up to 25m NLOS
TX INTERVAL: 5 sec (LIVE), 5 min (PRO)
BATTERY: 1 x 2/3A 3.6V LiSoCl2
LIFESPAN: 3 years
FCC, CE, RoHS, IP65
DIMENSIONS: 50mm x 40mm x 25mm
WEIGHT: 80g
Magnets, Adhesive Tape, M3 Screws
ABS-PC, Stainless Steel, Brass, PTFE, Lithium
16GB SD Card, stores 2 years of historical data locally
MQTT
GIGABIT Ethernet Lan
USB 3.0 for expansion
SMA Female for 2.4 GHz antenna
Recommended browsers (any device type), Chrome, Edge, Safari, Firefox running on Windows, Ubuntu or MacOS.
5V~2A USB-C (MAX)
FCC, CE, RoHS
DIMENSIONS: 55mm x 55mm x 30mm
WEIGHT: 160g
Keyhole slot, DIN rail
ABS-PC, Aluminum, Stainless Steel, Brass
